AT17/290117/

Corghi Electronic Cone to cone Winder BR

• Quantity:2
• Year:2002
• With n.36 Heads Each
• Double Side
• Grooved Drums 2,5 turns variable step
• Pitch 152 mm.(6°)
• Conicity 4°20′ on Mandrel
• Single head stop by engaging optical sensor
• Package size Max.290 mm.
• Driven Waxing device

• One yarn-stretcher each head
• Mechanical clearer with micrometric check
• Automatic stop at required diameter as standard
• Adjustable speed from 300 to 1200 mt./min.
• Main unit with speed regulation read on digital display
• Internal low creel
• One coaxial motor per head
• Electric Power supply : 380/3.
